When you look at red light therapy devices for pets, two numbers appear consistently: 660nm and 850nm. Understanding what these numbers mean — and why both matter — is the most useful thing you can know before choosing a device or starting a routine.
This guide explains what each wavelength does, why the difference is meaningful, and what the research tells us about how they work together.
What the Numbers Actually Mean
Wavelength is a measurement of light — specifically, the distance between the peaks of a light wave, expressed in nanometres (nm). Different wavelengths correspond to different colours and, critically, different biological behaviours when they interact with living tissue.
660nm sits at the red end of the visible spectrum — it's the warm red glow you can see when a device is active. 850nm sits just beyond the visible range, in the near-infrared zone — invisible to both human and animal eyes, but biologically active in a way that makes it the more studied of the two wavelengths for deeper tissue applications.
The reason these two specific numbers appear so consistently in the PBM literature isn't arbitrary. They fall within what researchers call the optical window of biological tissue — the range of wavelengths (roughly 600–1000nm) at which light penetrates tissue most effectively, without being fully absorbed at the surface or scattered before reaching target cells. Outside this window, light either can't reach the cells it's meant to influence, or generates heat rather than the photochemical response that makes PBM useful.
Anders et al. (2015) note that while many wavelengths have been studied in the photobiomodulation literature, 660nm and 850nm have accumulated the most substantial body of evidence — partly because they sit at complementary positions within this optical window, targeting different tissue depths within a single session.[3]
The 660nm Wavelength: Surface-Layer Support
At 660nm, red light penetrates to approximately 5–6mm beneath the skin surface. This makes it most effective for tissue in and just below the skin — including dermal structures, hair follicles, and superficial circulation.
How It Works at a Cellular Level
The mechanism is the same for both wavelengths, but the depth of effect differs. At 660nm, photons are absorbed primarily by Cytochrome c Oxidase (CCO) — a light-sensitive enzyme within the mitochondrial respiratory chain. As Chung et al. (2012) describe, this absorption triggers a cascade of downstream effects: increased electron transport activity, upregulation of ATP synthesis, and modulation of reactive oxygen species — all of which support normal cellular function in the treated tissue.[1]
At the surface level, this translates to support for skin integrity and coat health. Perego et al. (2016) examined the use of 660nm low-level laser therapy in dogs with sterile pyogranulomatous pododermatitis and found significantly better healing outcomes in treated animals compared to controls, with over 50% of treated dogs showing no lesion recurrence and no adverse effects reported.[4]
What 660nm Is Best For
- Skin and coat wellness
- Surface-level tissue support
- Conditions affecting the outer layers of the body
The 850nm Wavelength: Deeper Tissue Reach
At 850nm, light moves into the near-infrared range. The longer wavelength means less scattering as light passes through surface tissue, allowing it to reach significantly deeper — approximately 5–10mm below the skin surface, accessing muscle tissue, connective tissue, tendons, and structures adjacent to joints.
How It Works at a Cellular Level
The absorption mechanism is the same — CCO within the mitochondria — but because 850nm photons penetrate deeper before being absorbed, the cellular response occurs in tissue layers that 660nm light cannot reliably reach.
This deeper reach is the reason 850nm is the wavelength most consistently studied in the context of musculoskeletal support. Looney et al. (2018) conducted a randomised, blinded, placebo-controlled trial examining PBMT in 20 dogs with naturally occurring elbow osteoarthritis. Dogs receiving treatment showed statistically significant improvements in lameness scores compared to the sham group, and 9 out of 11 treated dogs were able to reduce their NSAID requirements — compared to 0 out of 9 in the control group (P = 0.0003).[5]
What 850nm Is Best For
- Deeper muscle and connective tissue support
- Active pets and those in regular exercise routines
- Senior pets for whom deeper tissue maintenance is a priority
Why Dual-Wavelength Devices Are the Standard
A device that delivers only one wavelength addresses only part of the picture. 660nm works at the surface; 850nm works deeper. Used separately, each covers its own range. Used together within the same session, they provide complementary coverage across both tissue depths — surface and deep — without requiring repositioning or separate sessions.
This is why dual-wavelength delivery has become the standard approach in both professional veterinary settings and home-use devices. A single session can support skin-level wellness and deeper tissue simultaneously, which is particularly relevant for pets where the target area — the back, hips, or shoulders, for example — involves multiple tissue layers at once.
The practical implication for device selection: if a device lists only one wavelength, or doesn't specify wavelengths at all, it's providing a partial approach. A device that specifies both 660nm and 850nm, active simultaneously, is giving you the full picture within each session.
The Optical Window: Why These Numbers and Not Others
It's worth explaining why 660nm and 850nm specifically — rather than, say, 700nm or 900nm — have accumulated the evidence base they have.
Biological tissue is not uniformly transparent to light. Water, haemoglobin, and melanin each absorb certain wavelengths strongly, which limits penetration. The optical window — roughly 600–1000nm — is the range where none of these major absorbers dominates, allowing light to pass through tissue with meaningful depth.
Within that window, 660nm and 850nm sit at particularly useful positions:
- 660nm is long enough to pass through the epidermis and reach dermal tissue, but short enough to be efficiently absorbed by CCO at that depth rather than passing through unused.
- 850nm is long enough to penetrate into deeper structures while remaining within the absorption range of CCO — beyond approximately 950nm, absorption by water begins to increase and the photochemical benefit diminishes.
This is why the research literature has converged on these two wavelengths rather than exploring the full spectrum equally. They represent the most practically useful positions within a biologically defined window — not a marketing decision.
Does the Light Work Through Fur?
This is one of the most common questions from pet owners, and the answer is yes — with some nuance.
Standard PBM wavelengths (660nm and 850nm) penetrate through typical pet coats. The fur itself is not a significant barrier for these wavelengths, as it doesn't contain the chromophores (light-absorbing molecules) that block penetration.
The variables that do matter:
- Coat density: Very thick double coats may reduce the amount of light reaching the skin surface, particularly for the shorter 660nm wavelength.
- Coat colour: Darker pigmentation absorbs more light at the surface. Dogs with very dark or black coats may experience slightly reduced surface-level penetration for 660nm, though 850nm is less affected by pigmentation.
- Device contact: Devices held or secured close to the body — rather than held at a distance — reduce the effect of coat density because less light is lost to scatter before contact.
For the vast majority of dogs and cats, coat type doesn't meaningfully change the suitability of at-home PBM. The practical consideration is mainly for very dense or very dark coats, where some owners choose to part the fur for targeted sessions — though this isn't necessary for routine wellness use.
Practical Implications for Your Pet's Routine
Understanding the wavelengths makes it easier to think clearly about what a session is doing and what to look for in a device.
If your focus is skin and coat wellness:
660nm is the primary wavelength doing that work. Ensure your device includes it and delivers it at sufficient intensity to reach the skin surface through your pet's coat.
If your focus is deeper tissue support:
850nm is the relevant wavelength. This is the one most studied for musculoskeletal applications and the one that reaches the tissue layers involved in movement and flexibility.
For general wellness maintenance:
A dual-wavelength device delivering both simultaneously is the most straightforward choice. Most pets benefit from support at both tissue depths, and a single session that covers both is simpler to manage than separate targeted sessions.
On session length and frequency:
Chung et al. (2012) note that in PBM research, the dose-response relationship is non-linear — more is not always better, and consistent moderate sessions tend to produce better outcomes than infrequent intensive ones.[1] For home use, 3–5 sessions per week of 15–20 minutes each represents a practical and well-supported routine for most pets.
How This Applies to the PawMoves Restore
The PawMoves Restore Red Light & Massage Wrap for Pets delivers both 660nm and 850nm simultaneously through 444 evenly distributed LEDs across the wrap surface. Both wavelengths are active in the same session, with three adjustable intensity levels to allow you to adapt the session to your pet's size, coat type, and individual preference.
The wrap format is worth noting in the context of wavelength delivery: because the device is secured directly against the body rather than held at a distance, light reaches the skin surface with minimal scatter loss — which is relevant particularly for the 660nm wavelength in denser-coated dogs.
Frequently Asked Questions
Is 850nm light visible to pets?
No. 850nm is in the near-infrared range, invisible to both human and animal eyes. Some devices include a faint visible indicator light so you can confirm the device is active, but the 850nm energy itself is not perceived as light by your pet.
Can my pet feel the light during a session?
The energy transfer in PBM is sub-thermal at home-use intensities — pets do not feel warmth or pressure from the light itself. Most owners report that their pets settle calmly during sessions, which is consistent with the quiet, non-invasive nature of the experience.
Does it matter which wavelength the device uses more of?
This depends on your focus. For skin and coat support, a higher proportion of 660nm is beneficial. For deeper tissue support, 850nm is the primary wavelength. A balanced dual-wavelength device covers both, which is the most practical choice for general wellness use.
How is this different from a standard heating pad?
A heating pad works through thermal conduction — it warms the surface of the body. PBM devices at home-use intensities are non-thermal; the biological effect comes from the photochemical response within cells, not from heat. This means PBM works through a fundamentally different mechanism and is comfortable for pets that don't tolerate external heat well.
Can I use this alongside my vet's recommended treatments?
At-home PBM is a wellness support tool — it is non-invasive, drug-free, and designed to complement an existing care routine. It is not a treatment and is not intended to replace veterinary advice or prescribed care. Always consult your vet before introducing any new wellness practice if your pet has an existing health condition.
Why do some devices use other wavelengths, like 630nm or 940nm?
Some devices use adjacent wavelengths that also fall within or near the optical window. These may be supported by some research, but 660nm and 850nm have the most substantial and consistently replicated evidence base in the veterinary PBM literature. When comparing devices, look for published research specific to the wavelengths listed, not just general claims about red or infrared light.
Related Reading
- Red Light Therapy for Pets: A Complete Guide to PBM and At-Home Wellness
- Is Red Light Therapy Safe for Pets? What Pet Owners Need to Know
- How to Choose a Red Light Therapy Device for Your Pet
- Red Light Therapy for Senior Dogs: Daily Support for Older Dogs
References
- Chung H, Dai T, Sharma SK, et al. The nuts and bolts of low-level laser (light) therapy. Ann Biomed Eng. 2012 Feb;40(2):516–533. PMID: 22045511. https://pubmed.ncbi.nlm.nih.gov/22045511/
- Hamblin MR. Photobiomodulation or low-level laser therapy. J Biophotonics. 2016 Dec;9(11-12):1122–1124. PMID: 27973730. https://pubmed.ncbi.nlm.nih.gov/27973730/
- Anders JJ, Lanzafame RJ, Arany PR. Low-level light/laser therapy versus photobiomodulation therapy. Photomed Laser Surg. 2015 Apr;33(4):183–184. PMID: 25844681. https://pubmed.ncbi.nlm.nih.gov/25844681/
- Perego R, Proverbio D, Zuccaro A, Spada E. Low-level laser therapy: case-control study in dogs with sterile pyogranulomatous pododermatitis. Vet World. 2016 Aug;9(8):882-7. PMID: 27651678. https://pubmed.ncbi.nlm.nih.gov/27651678/
-
Looney AL, Huntingford JL, Blaeser LL, Mann S. A randomized blind placebo-controlled trial investigating the effects of photobiomodulation therapy (PBMT) on canine elbow osteoarthritis. Can Vet J. 2018 Sep;59(9):959–966. PMID: 30197438. https://pubmed.ncbi.nlm.nih.gov/30197438/
